Adafruit Metro M7 with AirLift - Featuring NXP iMX RT1011

Get ready for our fastest Metro ever - the NXP iMX RT1011 microcontroller powers this board with a 500 MHz ARM Cortex M7 processor. There's 8 MB of execute-in-place QSPI for firmware + disk storage and 128KB of SRAM in-chip

Features

• NXP iMX RT1011 processor - ARM Cortex M7 processor running at 500 MHz, with 128KB SRAM and high-speed USB
• AirLift WiFi Co-processor, with TLS/SSL support, plenty of RAM for sockets, communication is over SPI and has CircuitPython library support ready to go for fast wireless integration
• 8MB of QSPI XIP FlashPower options - 6-12VDC barrel jack or USB type C
• UNO-shape so shields can plug in
• Reset button - Click to restart, double-click to enter UF2 bootloader
• Boot-mode switches to get into the ROM bootloader (you can always reload code over USB if TinyUF2 gets corrupted somehow)
• SWD connector for advanced debugging access.
• On/Off switch
• STEMMA QT connector for I2C devices
• On/User LEDs + status NeoPixel
• Works with CircuitPython!
• 53.2mm x 72mm / 2" x 2.8"
• Height (w/ barrel jack): 14.8mm / 0.6"
• Weight: 22.5

Resources

• Product Wiki
