WAGO 222-412 32A 2-Way Lever Connectors - Pack of 3
These high-quality official WAGO lever connectors are used across the globe for residential and industrial electrical work, and they're absolutely perfect for makers too!
If you need to join cables together quickly to prototype a project, these are ideal for the job and require no tools - the levers simply lift open and close. The levers are very stiff and snap down hard to ensure a solid connection, which is crucially important with electronics!
The connectors have a rated current of 32A, a nominal voltage of 400V (IEC) and are UL-listed so you can use them for your mains wiring (via an electrician!). Wires from 12-28AWG will fit and work well.
You will receive 3x 2-way WAGO lever connectors as pictured. Our WAGO connectors are sourced from reputable distributors, offering them in the convenient low quantities our customers demand for home automation projects.
Resources
Specification
- Connection method: Cage Clamp
- Number of ways: 2
- Cross-section [AWG]: 12-28 AWG
-
Rated voltage:
- IEC/EN: 400V
-
Rated current:
- IEC/EN: 32A
- Flammability rating per UL94: V0
- Model number: WAGO 221-412
- EAN: 4050821346470
Package Contents
- 3x WAGO 222-412 lever connectors
Description
These high-quality official WAGO lever connectors are used across the globe for residential and industrial electrical work, and they're absolutely perfect for makers too!
If you need to join cables together quickly to prototype a project, these are ideal for the job and require no tools - the levers simply lift open and close. The levers are very stiff and snap down hard to ensure a solid connection, which is crucially important with electronics!
The connectors have a rated current of 32A, a nominal voltage of 400V (IEC) and are UL-listed so you can use them for your mains wiring (via an electrician!). Wires from 12-28AWG will fit and work well.
You will receive 3x 2-way WAGO lever connectors as pictured. Our WAGO connectors are sourced from reputable distributors, offering them in the convenient low quantities our customers demand for home automation projects.
Resources
Specification
- Connection method: Cage Clamp
- Number of ways: 2
- Cross-section [AWG]: 12-28 AWG
-
Rated voltage:
- IEC/EN: 400V
-
Rated current:
- IEC/EN: 32A
- Flammability rating per UL94: V0
- Model number: WAGO 221-412
- EAN: 4050821346470
Package Contents
- 3x WAGO 222-412 lever connectors
