LoRa Expansion Board for Raspberry Pi Zero
Designed for the Raspberry Pi Zero, the Uputronics LoRa Expansion Board brings the ability to use the popular LoRa modules on the Pi Zero. Now available in two variants - 434MHz or 868MHz - please select an option before adding to your cart.
Supplied with suitable header and standoffs, the board allows you to select the module on either CE0 or CE1 depending on the location of the switch.
The RFM95/98W transceivers feature the LoRa long range modem that provides ultra-long range spread spectrum communication and high interference immunity whilst minimising current consumption.
The board has LED's for link and data. You can stack 2 of these boards (with different CE selections) on one Pi Zero. Supplied with a 2x20 way 4.93mm header and 2 standoffs for secure attachment to your Pi.
Resources
- Entry on pinout.xyz
- RFM95/98W Datasheet
Note
- These modules are sold as components and are not CE Compliant as they don’t have a specific application. The end user of these modules will need to submit their final product to get CE certification. They are intended for engineering, research or lab use only not for use in production.
Package Contents
- 1x LoRa Expansion Board for Raspberry Pi Zero
- Select frequency before adding to cart
